Total Solar Eclipse of -0512 Jul 11 (0513 Jul 11 BCE)

Fred Espenak

Introduction

eclipse map


The Total Solar Eclipse of -0512 Jul 11 (0513 Jul 11 BCE) is visible from the geographic regions shown on the map to the right. Click on the map to enlarge it. For an explanation of the features appearing in the map, see Key to Solar Eclipse Maps.

The instant of greatest eclipse takes place on -0512 Jul 11 at 01:17:57 TD (20:29:59 UT1). This is 0.9 days before the Moon reaches perigee. During the eclipse, the Sun is in the constellation Cancer. The synodic month in which the eclipse takes place has a Brown Lunation Number of -30110.

The eclipse belongs to Saros 57 and is number 37 of 73 eclipses in the series. All eclipses in this series occur at the Moon’s ascending node. The Moon moves southward with respect to the node with each succeeding eclipse in the series and gamma decreases.

The solar eclipse of -0512 Jul 11 is an exceptionally long total eclipse with a duration at greatest eclipse of 06m21s. It has an eclipse magnitude of 1.0713.

The total solar eclipse of -0512 Jul 11 is preceded two weeks earlier by a penumbral lunar eclipse on -0512 Jun 25, and it is followed two weeks later by a penumbral lunar eclipse on -0512 Jul 25.

These eclipses all take place during a single eclipse season.

The eclipse predictions are given in both Terrestrial Dynamical Time (TD) and Universal Time (UT1). The parameter ΔT is used to convert between these two times (i.e., UT1 = TD - ΔT). ΔT has a value of 17278.0 seconds for this eclipse. The uncertainty in ΔT is 434.8 seconds corresponding to a standard error in longitude of the eclipse path of ± 1.82°.

The following links provide maps and data for the eclipse.

The tables below contain detailed predictions and additional information on the Total Solar Eclipse of -0512 Jul 11 .


Eclipse Data: Total Solar Eclipse of -0512 Jul 11

Eclipse Characteristics
Parameter Value
Eclipse Magnitude 1.07135
Eclipse Obscuration 1.14779
Gamma 0.03213
Conjunction Times
Event Calendar Date and Time Julian Date
Greatest Eclipse -0512 Jul 11 at 01:17:56.7 TD (20:29:58.7 UT1) 1534241.354151
Ecliptic Conjunction -0512 Jul 11 at 01:18:16.7 TD (20:30:18.7 UT1) 1534241.354383
Equatorial Conjunction -0512 Jul 11 at 01:17:58.8 TD (20:30:00.8 UT1) 1534241.354176
Geocentric Coordinates of Sun and Moon
-0512 Jul 11 at 01:17:56.7 TD (20:29:58.7 UT1)
Coordinate Sun Moon
Right Ascension06h50m26.4s06h50m26.3s
Declination+23°14'42.1"+23°16'39.4"
Semi-Diameter 15'47.2" 16'37.7"
Eq. Hor. Parallax 08.7" 1°01'01.5"
Geocentric Libration of Moon
Angle Value
l -1.4°
b -0.0°
c 6.7°
Prediction Paramaters
Paramater Value
Ephemerides JPL DE406
ΔT 17278.0 s
k (penumbra) 0.2725076
k (umbra) 0.2722810
Saros Series 57 (37/73)

Explanation of Solar Eclipse Data Tables

Penumbral Shadow Contacts and Extremes: Total Solar Eclipse of -0512 Jul 11

Contacts of Penumbral Shadow with Earth
Contact Event Contact Time
TD
Time
UT1
Latitude Longitude
First External ContactP122:39:35.817:51:37.800°30.5'N178°17.8'W
First Internal ContactP200:29:45.219:41:47.203°04.0'N153°03.9'E
Last Internal ContactP302:06:08.621:18:10.504°11.3'N047°54.6'W
Last External ContactP403:56:15.423:08:17.401°37.8'N076°32.4'W
Extreme Northern and Southern Path Limits of Penumbra
Contact Event Contact Time
TD
Time
UT1
Latitude Longitude
North Extreme Path Limit 1N123:59:41.119:11:43.030°34.3'N147°11.9'E
South Extreme Path Limit 1S123:38:46.618:50:48.627°38.0'S179°52.4'W
North Extreme Path Limit 2N202:36:12.121:48:14.031°38.8'N041°52.7'W
South Extreme Path Limit 2S202:57:06.522:09:08.526°32.1'S074°50.1'W

Explanation of Penumbral Shadow Contacts and Extremes Tables

Umbral Shadow Contacts and Extremes: Total Solar Eclipse of -0512 Jul 11

Contacts of Umbral Shadow with Earth
Contact Event Contact Time
TD
Time
UT1
Latitude Longitude
First External ContactU123:33:15.518:45:17.401°05.4'N168°02.3'E
First Internal ContactU223:36:03.618:48:05.601°08.2'N167°19.1'E
Last Internal ContactU302:59:48.522:11:50.502°15.6'N062°09.4'W
Last External ContactU403:02:38.722:14:40.702°12.7'N062°53.2'W
Extreme Northern and Southern Path Limits of Umbra
Contact Event Contact Time
TD
Time
UT1
Latitude Longitude
North Extreme Path Limit 1N123:34:57.618:46:59.501°49.2'N167°17.9'E
South Extreme Path Limit 1S123:34:22.918:46:24.900°24.4'N168°03.1'E
North Extreme Path Limit 2N203:00:55.422:12:57.302°57.0'N062°08.3'W
South Extreme Path Limit 2S203:01:30.522:13:32.501°31.2'N062°54.0'W

Explanation of Umbral Shadow Contacts and Extremes Tables

Central Line Extremes and Duration: Total Solar Eclipse of -0512 Jul 11

Extreme Limits of the Central Line
Contact Event Contact Time
TD
Time
UT1
Latitude Longitude
Extreme Central Line Limit 1C123:34:39.618:46:41.501°06.8'N167°40.7'E
Extreme Central Line Limit 2C203:01:13.622:13:15.602°14.1'N062°31.3'W

Explanation of Central Line Extremes Table

Greatest Eclipse and Greatest Duration
Event Time
TD
Time
UT1
Latitude Longitude Sun
Altitude
Sun
Azimuth
Path Width Central
Duration
Greatest Eclipse01:17:56.720:29:58.725°14.1'N160°07.6'E 88.0° 179.4° 232.2 km06m20.89s
Greatest Duration01:18:36.420:30:38.425°14.3'N127°26.7'W 88.0° 190.0° 232.2 km06m20.90s

Explanation of Greatest Eclipse and Greatest Duration

Polynomial Besselian Elements: Total Solar Eclipse of -0512 Jul 11

Polynomial Besselian Elements
-0512 Jul 11 at 01:00:00.0 TD (=t0)
n x y d l1 l2 μ
0 -0.17400 0.03027 23.2460 0.53251 -0.01358 195.3665
1 0.58062 0.00625 -0.0035 -0.00004 -0.00004 14.9992
2 0.00002 -0.00017 -0.0000 -0.00001 -0.00001 0.0000
3 -0.00001 -0.00000 - - - -
Tan ƒ1 0.0046147
Tan ƒ2 0.0045917

At time t1 (decimal hours), each besselian element is evaluated by:

x = x0 + x1*t + x2*t2 + x3*t3 (or x = Σ [xn*tn]; n = 0 to 3)

where: t = t1 - t0 (decimal hours) and t0 = 1.000

Explanation of Polynomial Besselian Elements

Links for the Total Solar Eclipse of -0512 Jul 11 (0513 Jul 11 BCE)

Links to Additional Solar Eclipse Information

Calendar

The Gregorian calendar (also called the Western calendar) is internationally the most widely used civil calendar. It is named for Pope Gregory XIII, who introduced it in 1582. On this website, the Gregorian calendar is used for all calendar dates from 1582 Oct 15 onwards. Before that date, the Julian calendar is used. For more information on this topic, see Calendar Dates.

The Julian calendar does not include the year 0. Thus the year 1 BCE is followed by the year 1 CE (See: BCE/CE Dating Conventions). This is awkward for arithmetic calculations. Years in this catalog are numbered astronomically and include the year 0. Historians should note there is a difference of one year between astronomical dates and BCE dates. Thus, the astronomical year 0 corresponds to 1 BCE, and astronomical year -1 corresponds to 2 BCE, etc..

Eclipse Predictions

Predictions for the Total Solar Eclipse of -0512 Jul 11 were generated using the JPL DE406 solar and lunar ephemerides. The lunar coordinates were calculated with respect to the Moon's Center of Mass. The predictions are given in both Terrestrial Dynamical Time (TD) and Universal Time (UT1). The parameter ΔT is used to convert between these two times (i.e., UT1 = TD - ΔT). ΔT has a value of 17278.0 seconds for this eclipse. The uncertainty in ΔT is 434.8 seconds corresponding to a standard error in longitude of the eclipse path of ± 1.82°.
